20X PTZ Auto Tracking Optical Camera

Nugens VCM20B

20X PTZ Auto Tracking Optical Camera

AI Humanoid Tracking, USB/HDMI Plug and Play

20X PTZ Auto Tracking Optical Camera Icon

AI Human Tracking

Built-in high-speed processor as well as the use of exclusive advanced image processing and analysis algorithms, the user can choose real-time tracking and area tracking according to the use of the environment.

AI-Tracking

USB Plug & Play without Complicated Settings

The VCM20B is designed to be quick to use and easy to operate. You only need to connect it to a computer, and it will start tracking and functioning.

20X PTZ Auto Tracking Optical Camera USB Plug

ON/OFF Tracking Function
with Remote Controller

A remote control is included, and the tracking function can be turned on or off in the Menu, which is intuitive and convenient to operate.

20X PTZ Auto Tracking Optical Camera Len,Remote

Support Advanced Settings
for Advanced Users

Apart from easy to use for the basic users, VCM20B can also satisfy advanced users at the same time. Provide advanced settings and functions, allowing advanced users to customize the tracking range according to different needs, to meet the diverse needs that arise in different scenarios.

20X PTZ Auto Tracking Optical Camera Setting
20X PTZ Auto Tracking Optical Camera zoom

Built-in High Magnification
Optical Zoom Lens

20x HD optical zoom with rapid auto focus to capture every single detail, 2 million high resolution 56° wide-angled lens.

20X PTZ Auto Tracking Optical Camera Positions

Preset Position - Quick
Switching Position

You can customize and preset 10 positions of camera presets in different directions. When speaking in a multi-person conference or event, you can quickly switch to the position or angle, and with the Zoom In/Out of the lens to make the picture extra vivid.

20X PTZ Auto Tracking Optical Camera Photo

Top Sensor, Present High-Quality Images

With a 1/2.8-inch 2.07-megapixel high-quality CMOS image sensor, the maximum resolution can reach 1920 × 1080, and the output frame rate is up to 60 frames per second (60 fps), presenting a clear and realistic HD video, vividly showing the expressions and movements of people.

不同攝影機影像清晰度對比

Noise Reduction Tech

Low noise CMOS effectively ensures an ultra-high signal-to-noise ratio of the output video. Advanced 2D + 3D noise reduction technology is used to further reduce noise while ensuring image clarity.

20倍追蹤光學專業級PTZ視訊攝影機旋轉角度示意圖

Quiet Operation

High-precision stepper motor and precision motor drive controller to ensure that the head running smoothly, and with low noise.

20倍追蹤光學專業級PTZ視訊攝影機吊頂示意圖

Built-in Gravity Sensor

Supports the automatic image flip function, making it simple to set up and use in engineering.

Video Output Interfaces

Support HDMI, SDI, USB3.0, LAN support audio and video output at the same time; LAN interface supports POE power, USB3.0 support dual stream, SDI support in 1080P @60 fps format transmission up to 100 meters.

Compatible with Mainstream Conference Software

Support current mainstream video conferencing and live streaming platforms, such as YouTube, Facebook, Zoom, WebEx, Google Meet, Microsoft Teams, Skype, Line, WeChat.

Powerful and Complete

Snapshot / Video Recording / Livestream / Conference / Whiteboard / Document Camera
e-Learning / Conferencing / Video Tutorial / Live Stream / e-Education

CamSwitcherPro
CamSwitcherPro
  • Large preview window with user-friendly graphical interface.
  • Able to choose preferred resolution for preview and settings – Support 4K Ultra-HD
  • Capture HD images, HD videos, Time-Lapse, Picture-in-Picture and Burst.
  • Time-Lapse Comparison, Annotation and Animated Title
  • Support RTMP Live Stream (YouTube or Facebook)
  • Built-in Whiteboard and Blackboard
  • Support Screen-Sharing and Virtual Camera
  • Supported Operating System | Windows and macOS
CamSwitcherPro Win10程式下載
CamSwitcherPro macOS程式下載
CamSwitcher NuRemote示意圖

Remotely Control

With the NuRemoteApp, you can control the PC via mobile phone or tablet and connect to Nugens software such as CamSwitcherPro, and SmartScheduler Advertising Software. The mobile device can remotely control Nugens devices such as PTZ camera, and speakerphone. NuRemoteApp uses Wi-Fi connection technology to install the software and app on the PC and mobile phone, simulate the mouse, keyboard and touchpad, and add shortcut keys such as direction keys, which can remotely control the PC without being limited by distance and angle. In this way, you can directly use your mobile phone or tablet to take pictures, video, resolution adjustment, image rotation, zoom, freeze images, brush annotation and other functions in the video conference, making the conference control more flexible.

Download

Suitable for Various Applications

VCM20A is suitable for various fields and purposes, such as conferencing, online learning for schools, educational lecture, live broadcasting.

Conference Photo

Conference

Online Learning Photo

Online Learning

Lecture Photo

Lecture

Live Stream Photo

Live Stream

SCHEMATIC VIEW

20X PTZ Auto Tracking Optical Camera View
20X PTZ Auto Tracking Optical Camera Port

Specifications

Model VCM20B
Sensor 1/2.8-inch-hight quality HD CMOS sensor
Effective Pixels 2.07 MP、16:9
HDMI/SDI Video formats 1080P60、1080P50、1080P30、1080P25、720P50、1080P59.94、1080P29.97、720P59.94
USB 3.0 output supports video formats including Main stream
MJPEG/H264: YUY2/NV12:
1920x1080 1920x1080
1600x896 1280x720
1280x720 1024x576
1024x576 800x600
960x540 800x448
800x600 640x360
800x448 640x480
720x576 480x270
720x480 320x180
640x360
640x480
480x270
352x288

Subcode stream
MJPEG/H264: YUY2/NV12:
1920x1080 1920x1080
1600x896 1280x720
1280x720 1024x576
1024x576 800x600
960x540 800x448
800x600 640x360
800x448 640x480
720x576 480x270
720x480 320x180
640x360
640x480
480x270
352x288
Field of View 3.2°(Narrow Angle)、56°(Wide Angle)
Aperture Factor F1.5~F3.0
Minimum Illumination 0.5Lux(F1.8 AGC ON)
Digital NoiseReduction 2D, 3D digital noise reduction
Spotlight Mode Auto, Manual, One-touch focus
White Balance Mode Auto, Manual, One-touch White Balance, Specified Color Temperature
Exposure Mode Auto, Manual, Shutter Priority, Aperture Priority, Brightness Priority
Aperture Parameters F1.8 ~ F11、CLose
Shutter Speed 1/25~1/10000
Backlight Compensation ON/OFF
Dynamic Range Closure, 1 to 8
Image Adjustment Brightness, Chroma, Saturation, Contrast, Sharpness, B&W Mode, Gamma Curve
Signal-to-Noise Ratio >50dB

Auto Tracking

Real-time Tracking The longest tracking distance can reach 6-7 meters, and can support the speaker to walk at a speed of 3-4 miles
Area Tracking Support setting 4 tracking areas, support horizontal -170°~+170°, vertical -30°~+90° within the setting area

Port

Product Interface HDMI, LAN, USB3.0(B-type port、USB2.0 compatible), LINE-IN, RS232-IN, RS232-OUT, RS422(RS485 compatible), rotary dip code, DC12V power supply, power switch
Audio Input Dual 3.5mm linear inputs
Video encoding format LAN interface: primary stream and secondary stream both support H.265, H.264 USB3.0 interface: main stream support YUY2, MJPG, H264, NV12
Audio Compression Format AAC、MP3、G.711A
network interface 110M/100M/1000M adaptive Ethernet port, support POE power supply, support audio and video output
network Protocol RTSP、RTMP、ONVIF、GB/T28181、VISCA OVER IP、IP VISCA、RTMPS、SRT
Support remote upgrade, remote reboot, remote reset
Control Interface RS232-IN、RS232-OUT、RS422 compatible with RS485、3G-SDI Output(VCM20B)
USB Communicatio Protocol UVC(video communication protocol),UAC(audio communication protocol)
Serial Communication Protocol VISCA / Pelco-D / Pelco-P;baud rate support 115200/38400/9600/4800/2400
Power Connector HEC3800 Power Socket (DC12V)
Power Adapter Input AC110V-AC220V; Output DC12V/2.5A
Input Voltage DC12V
Input current <1A
Power consumption of the whole machine <12W

PTZ Specifications

horizontal rotation -170°~+170
tilt -30°~+30°
Horizontal control speed 0.1°~100°/sec
Pitch control speed 0.1°/s to 45°/s
Preset Bit Speed Horizontal: 100°/s, Pitch: 45°/s
Number of Preset Bits User settable up to 255 preset positions (10 for remote control)

Other Specifications

Storage Temperature -10℃~+70℃
Storage Humidity 20%~95%
Working Temperature -10℃~+50℃
Working Humidity 20%~80%
Product Size 81mm (L) x 115mm (W) x 149mm (H)
Product Weigh 1.15kg
What is in the box? Power transformer, RS232 control cable, USB 3.0 transmission cable, Remote controller, User manual, Wall mount kit
